The Series 5integrated suspension spot welding guns all have a fully enclosed protectivestructure design at the tail, with large cylinder pressure output and moderatevolume of the machine. Furthermore, two types of transformers – the mediumfrequency and power frequency transformers are available, which can be used incombination as per the welding requirements. With full consideration to thecompatibility, the transformers with C-type and X-type welding gun structuresare interchangeable, which lowers the customer's inventory pressure and reducethe use cost.
The integrated suspension spot welding gun is made by the assembling process, wherethe transformer and the gun arm are integrated and fixed on the rotating disc.The inner ring and the outer ring of the rotating disc are connected by a steelball structure, which has the characteristics of flexible rotation and noclamping stagnation. The welding gun can rotate by 360 degrees through therotating disc, and the rotating disc is provided with a locking mechanism whichcan be locked at any angle, thus effectively meeting some specific weldingpostures. After the welding is completed with specific postures, the weldinggun can rotate normally once unlocked.
The body of welding gun is made with hard die casting process, and has compactstructure, high density, high strength and few defects such as sand holes andair holes.
Solenoid valves and other outsourced parts are well-known foreign brands withstable performance and long service life.
The cable at the tail of the welding gun is fixed by a wire harness frame,which can effectively prevent the cable from friction damage when the weldinggun twist.
