Series 2 integrated suspension spot welding gunhas a protective plate structure design at its tail, with large cylinderpressure output and small volume of the machine. Furthermore, two types oftransformers – the medium frequency and power frequency transformers areavailable, which can be used in combination as per the weldingrequirements.
The integrated suspension spot welding gun ismade by the assembling process, where the transformer and the gun arm areintegrated and fixed on the rotating disc. The inner ring and the outer ring ofthe rotating disc are connected by a bearing structure, which has the characteristicsof flexibility and stability. The welding gun can rotate by 360 degrees throughthe rotating disc, and the rotating disc is provided with a locking mechanismwhich can be locked at any angle, thus effectively meeting some specificwelding postures. After the welding is completed with specific postures, thewelding gun can rotate normally once unlocked.
The body of welding gun is made with hard diecasting process, and has compact structure, high density, high strength and fewdefects such as sand holes and air holes.
Solenoid valves and other outsourced parts arewell-known foreign brands with stable performance and long service life.
The cable at the tail of the welding gun isfixed by a wire harness frame, which can effectively prevent the cable fromfriction damage when the welding gun twist.
