The tail of the Series 3 integrated suspensionspot welding gun is designed with lightweight structure, with stable aircylinder pressure output. The body is small and light. The transformer is ofpower frequency type and is applied to stations with complex operating postureand high turnover frequency of welding gun. Due to the small size of thewelding gun, the welding pressure and power are limited and are generally usedfor thin plate welding.
The integrated suspension spot welding gun ismade by the assembling process, where the transformer and the gun arm areintegrated and fixed on the rotating disc. The inner ring and the outer ring ofthe rotating disc are connected by a steel ball structure, which has thecharacteristics of flexible rotation and no clamping stagnation. The weldinggun can rotate by 360 degrees through the rotating disc, and the rotating discis provided with a locking mechanism which can be locked at any angle, thuseffectively meeting some specific welding postures. After the welding iscompleted with specific postures, the welding gun can rotate normally onceunlocked.
The body of welding gun is made with hard diecasting process, and has compact structure, high density, high strength and fewdefects such as sand holes and air holes.
Solenoid valvesand other outsourced parts are well-known foreign brands with stableperformance and long service life.
The cable at the tail of the welding gun isfixed by a wire harness frame, which can effectively prevent the cable fromfriction damage when the welding gun twist.
